The nanodac offers an optional Dual Programmer supporting up to 100 programs locally, each program supporting 25 segments. Heat Treatment is one of the many processes that often need to vary the setpoint of the control process over a set period of time this is achieved by using a set-point program. Functionality includes one of the best autotune facilities available along with overshoot inhibition (cutbacks) compensation for power fluctuations using power feedforward linear, fan, oil and water cooling. This control functionality utilises the advanced Eurotherm PID algorithm providing high performance and reliability to your process. The nanodac instrument can also provide two independent control loops (optional). An additional 30 virtual channels can be utilised to provide maths, counter, slave communications and totaliser functionality within the instrument.Įurotherm Data Reviewer is the ideal choice for the viewing, analysis and printing of historical data files acquired from Eurotherm data acquisition equipment. The four universal input channels provide high accuracy (suitable for use in Nadcap applications) and 125ms parallel sampling.
Proven data integrity and GAMP templates help to simplify validation and auditing processes, with electronic signing and. As well as multiple real-time views and historical review on the product, multiple data archiving strategies are provided utilising the 50MB onboard Flash memory, removable USB and data transfer via FTP to a specified server. Using the BACnet protocol, the nanodac Recorder/Controller can be easily integrated into a Building Management System (BMS) for applications such as heating, ventilation, air-conditioning, lighting and access control. The nanodac recording functionality utilises the secure strategies and UHH format developed by Eurotherm through years of recording expertise. The unit also provides user wiring from the front of the product for detailed configuration without the need to connect to a PC. Views include: Horizontal and vertical trends Horizontal and vertical bar graphs Numeric Alarm panel, Alarm status, and control loops. The 3.5” TFT display offers incredibly clear visualisation of process parameters with a wide selection of configurable views to best suit the application. Please refer to the Installation sheet or User Guide for wiring instructions.Īn optional IP66 rated Wash-down bezel has been made available in this release, making the nanodac suitable for applications in Food & Beverage or CIP/SIP.
This release provides support for Isolated DC Outputs in option slots OP1, OP2 and OP3. The nanodac also provides remote access to a further 100 programs that can be easily retrieved via FTP or USB memory stick. The second is a diagnostics page that can be used during initial setup and commissioning, to test the connection, between the Client and/or Server. point of the control process over a set period of time this is achieved by using a set-point program. EtherNet/IP provides two user pages, the first is an overview of all the process parameters (data points) being addressed via the communications. When enabled, EtherNet/IP allows the nanodac to act as either a Client or a Server and provides data recording for up to 30 process parameters (via virtual channels). Both allow alarm and discrete input logging, communications with other devices, results available in the data record, electronic signatures and batch data recording.Īvailable as an option, the nanodac recorder/controller can be easily integrated with an existing instrument network and act as local data historian. For more demanding applications, the Versadac recorder provides a back of panel solution with almost unlimited capacity. Historical data can be automatically imported through the use of SFTP/FTP communications from Ethernet enabled devices or directly from an SFTP/FTP server.The Eurotherm nanodac™ recorder/controller offers four channels of precision analogue batch recording, easily meeting the requirements of regulators for accuracy and repeatability, and data logging requirements of 21 CFR 11. Data can be refined further by changing the date range, searching for recording devices by name/recording group from automatically generated lists, or by typing in the name of the device/record.ĭata access is fast and easy. Imported data is automatically organized by group and batch which allows the user to easily find what they are looking for.
#Nanodac recorder controller install#
The browser-based single installation means you can install the application once on a server and provide remote access to your users, removing the need to store and maintain access on multiple PC’s.
#Nanodac recorder controller series#
6000 series Paperless graphical recorders.
#Nanodac recorder controller software#
The Eurotherm Data Reviewer software application is designed for the viewing, analysis, and printing of historical data files acquired from Eurotherm data acquisition equipment such as:
